Data Centre Design & Build
Multithread Solutions approach to Address Data centre Architecture Requirement:
Phase – I : Data Collection
- Assess the requirement
- Requirement Study and Analysis
- Site survey and feasibility survey
- Determine the category of Data centre to be build out
Phase – II : Design Conceptualization
- Prepare Data Centre Design based on information collection in phase-I
- Size the solution of every specific component of data centre
- Articulate the solution
Phase – III: Product Realization – Building Data centre
- Plan and execute DC
- Installation & Commissioning of Specific Solution as per design
- Integrate the DC solutions i.e. Passive infra, Power, Cooling etc.
Offerings in Data Center Cooling
Room-Based Cooling
In room-oriented architecture the cooling devices are deployed to address the room temperature and work together to combat high total heat load in the room. Typical room architecture includes multiple air conditioning units with either direct uninhibited access to vents and grilles or partially covered by raised flooring or overhead plenum configurations.
Raw Oriented Cooling
Room cooling is appropriate for low density datacenter but Latest generation high density and variable density IT equipment create conditions that room cooling was never intended to address, resulting in cooling systems that are inefficient and unpredictable. Row-oriented and rack-oriented cooling architectures have been developed to address these problems.In a row-oriented architecture the cooling units are associated directly with rows of IT devices and are usually designed into the infrastructure from inception. Greater predictability, more accurate and shorter airflow paths plus higher overall densities are the primary advantage of row over room architecture. Raw Oriented cooling can be considered in mentioned scenarios:
- Rack based, Raw Based & Room Based Cooling
- Determine the Critical Load and Heat Load
- Determine the Cooling Methodology & Cooling Delivery Methodology
- Cooling Redundancy (2N, N+1 etc) – choose right solution which suits requirement for specific data center.
- One Row of Rack run high density Application (Blade Server).
- Another Row satisfies lower power density application.
- N+1 and 2N targeted at specific rows.
- Implemented Without Raised Floor.
- Simple and Predefined Layout Architectures.
- Predictable Performance.
- Immune to the effects of room geometry or room constraints.
- Efficient cooling is key, our solutions offer highest cooling efficiency by adopting containment – Hot Aisle or Cold Aisle.
Hot Aisle Containment Cooling Solutions
Most IT equipment breathes front to rear. Hot aisle/cold aisle aligns the cabinets in rows around this concept, with the server exhausts of each row facing one another, becoming the hot aisle. Hot Aisle Containment immediately captures server exhaust air and restricts its entry to the rest of the data center. The exhaust air’s destination depends on the containment configuration.
Cold Aisle Containment Solutions
Cold Aisle Containment augments its predecessor’s (hot aisle/cold aisle) arrangement by enclosing the cold aisle. The aisle then becomes a room unto itself, sealed with barriers made of metal, plastic, or Plexiglas.
Rack Oriented Cooling
Rack-oriented architectures the cooling device is designed into the rack itself and directs even shorter airflow in exactly defined paths that are immune to changes in room climate and physical constraints. The highest power density and maximum capacity for the cooling device is achieved in this configuration
Major Benefits of Rack Oriented Cooling
Enhanced Cooling Efficiency: Targets specific equipment, reducing energy waste.
Reduced Energy Consumption: Uses localized cooling, lowering overall power usage.
Scalability: Easily adaptable to growing data center needs.
Improved Equipment Lifespan: Maintains optimal temperatures, preventing overheating.
Space Optimization: Designed for compact and efficient cooling within server racks.
Advantage
Multithread can help you to provide state of art Data Centre Infrastructure, our industry aligned technology architects provide solutions that work and adds exceptional value. We understand business intricacy; we know our technology and we know how to bring this knowledge and understanding together to provide end-to end Datacenter Infrastructure solution and integrating it to work seamlessly.
Multithread is trusted and competent system integrator for data center consulting and turnkey solutions in this space. Our broad offering & project experience, specializing in designing data centers, server room and technical spaces that integrate, best-of-breed, critical infrastructure technologies and result in continuously available, scalable, redundant, fault-tolerant, manageable and maintainable mission critical environments.
